KiloVolt Large Display Indicator

KiloVolt Large Display Indicator

Large display indicators measures and displays the Kilovolt from inputs like 63.5VAC, 4-20mA and data received from other equipment. It meets high accuracy of 0.1% to measure Kilovolt. The large display is for clear visibility of the kilovolt reading from a long distance. It is equipped with high bright red color 7 segment displays. These are commonly used in Power plants, Substations, Manufacturing units and Field environments to provide direct Kilovolt measurements.

Features

  • High Bright 7 segment Display to view from long distance
  • It Measures Kilovolt from 63.5V AC or 4-20mA current or signal received through Ethernet or RS485/RS232
  • Measures the Kilovolt with an accuracy of 0.1%
  • Available in 50mm, 100mm, 144mm& 300mm sizes
  • The input power supply can be customized
  • 10/100Mbps is the speed for Ethernet input
  • Power Over Ethernet option available
  • Wireless display option available with limited range
  • Rugged and Robust display
  • Isolated and protected Interfaces
  • Cabinets made up of MS/SS/Aluminium
  • Cabinet with powder coat finish
  • Wall / Panel / Tabletop mountable
  • Protection class from IP 20 / IP 55 available
  • Front plate covered with Red color acrylic sheet

Applications

  • Power Plants
  • Substations
  • Industries
  • Educational institutions

Specifications

Power Supply
Standard 100 to 270V AC, 1φ, (47Hz to 63Hz)
or 100V to 370V DC
Custom 36V to 72V DC (48V), 18V to 36V DC (24V)
Power Consumption <10W
Display
Display Type 7 Segment Display
No of Digit 6 Digit
Format XXXX.XX
Display Size 50mm/100mm/144mm/300mm
Color Bright Red
Input Signal
Voltage Input* Voltage : 63.5V AC
Value: Based on Customer specified value
Connector: Pluggable Terminal block
Current Input* Current : 4-20mA or 0-20mA
Value: Based on Customer specified value
Connector: Pluggable Terminal block
Ethernet Input* Packet: Customer should specify
Connector: RJ45
Speed: 10/100Mbps
RS485/RS232 Input* Based on Customer specified protocol, Baudrate, data bit, stop bit & parity
Connector : Pluggable Terminal / DB9
Wireless Input* Input: Wireless Antenna
SANDS Wireless transmitter should be used
Environment
Operating Temp 0°to 50°C
Humidity 95% Non-Condensing
Mechanical
Enclosure Wall/Panel/Table Top Mountable
Dimension 50mm Display – 484mm x 74mm x 100mm
100mm Display – 750mm x 56mm x 170mm
144mm Display – 922mm x 56mm x 212mm
300mm Display – 1620mm x 56mm x 360mm
Protection Class IP20, IP55*
Note: * Optional
